Table 3-50 Cable ring specifications
Name
Dimensions (H x W x D)
Weight
Standard cable ring
55 mm x 48 mm x 188.6 mm
0.163 kg
Small cable ring
55 mm x 48 mm x 44 mm
0.096 kg
Cable Tray
A cable tray is used for forward and backward cabling. It uses mounting ears to facilitate
device installation.
Figure 3-37 Cable tray
Table 3-51 Cable tray specifications
Dimensions (H x W x D)
Weight
Space Occupied
43.6 mm x 482.6 mm x 250 mm
1.89 kg
1 U
