Huawei FusionModule500

FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
3 System Architecture
Issue 05 (2019-11-22)
Copyright © Huawei Technologies Co., Ltd.
24
Item
Specifications
Maximum input current
19 A
Number of phases
1
Input power factor (full load)
> 0.99
input frequency
Rated frequency: 50 Hz/60 Hz
Range: 40–70 Hz
Total distortion of the input current
waveform (THDi)
< 5%
Output voltage
220 V/230 V/240 V
Tolerance: ±1%
Output frequency

Normal mode: 50 Hz/60 Hz (±6 Hz)

Battery mode: 50 Hz/60 Hz (±0.05%)
Output power factor
0.9
Efficiency
94%
Communications port (optional)
USB/RS485
Dimensions (W x D x H)
430 mm x 615 mm x 86 mm
Weight
14 kg
Noise
< 55 dB
3.2.1.3 6 kVA UPS
Figure 3-4 UPS2000-G
