FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
2 Typical Application Scenarios and Configurations
Copyright © Huawei Technologies Co., Ltd.
Two-Cabinet Solution
Figure 2-8 Converged Cabinet + battery cabinet
Table 2-8 Typical configuration 2
Cabinet dimensions (W x D x H)
600 mm x 1100 mm x 2000 mm
UPS2000-G, PDU5000, rPDU, battery, and
transformer
NOTE
If batteries are configured, battery packs are not
required.
