FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
Copyright © Huawei Technologies Co., Ltd.
Figure 3-22 CIM bottom view
(3) Default button (IP
reset)
(4) ADDR dual in-line package (DIP) switch (RS485
communications address)
(5) 12V 2A port (power
input)
Power Port
Figure 3-23 Power port pins
Table 3-27 12 V, 2 A port pin definitions
In this scenario, an external
power module is adopted to
supply 12 V DC operating
voltage.
To Next Page
