Huawei FusionModule500

FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
3 System Architecture
Issue 05 (2019-11-22)
Copyright © Huawei Technologies Co., Ltd.
55
Indicator
Color
Meaning
Status
Description
Measure
ALM
Red
Alarm indicator
Steady on
The actual number
of online devices
is less than the
value of BIM
number.
Check the value
of BIM number,
the BIM cable
connection, and
the BIM
indicators.
Off
The actual number
of online devices
equals the value of
BIM number.
Requires no
handling.
PWR
Green
Power indicator
Steady on
Board power
indicator.
Requires no
handling.

If an indicator blinks at long intervals, it is blinking at 0.5 Hz, that is, on for 1s and then off for 1s.

If an indicator blinks at short intervals, it is blinking at 4 Hz, that is, on for 0.125s and then off for
0.125s.

If an indicator blinks at super short intervals, it is blinking at 10 Hz, that is, on for 0.05s and then off
for 0.05s.

Blinking intermittently at super short intervals means an indicator blinks at super short intervals for
0.5s and then remains off for 0.5s.
Networking Switch
Table 3-37 Networking switch description
Name
Definition
Function
Button pressing
Press the button for less than 1s.
CIM blinking function
Button pressing
Press and hold the button for
more than 1s but less than 5s.
Creates a network if no
network has been created.
Switches between network
organization and data
transmission if a network has
been created.
Button holding down
Press and hold the button for
more than 10s but less than 20s.
Clears the current network
(including the network
parameters of all the online
BIMs).
