2-1
2 Hardware Installation
2.1 Selecting a Position for the Router
Place the router in a stable and well-ventilated location and do not expose it to direct
sunlight. For best results with the router WLAN function, place the router as follows:
Place the router in an open space and ensure that there are no obstacles, such as
walls and columns, between your computer and the router. Otherwise, the
transmission of radio signals on the WLAN may be negatively impacted.
Ensure that the router and your computer are far from the electric appliances (such
as a microwave oven) that generate strong magnetic or electric fields.
2.2 Installing the Hardware
Adjust the antennas by referring to the direction of the arrows in the following figure.
When installing the base, ensure that the arrow on the base points in the same direction as
the front panel of the router.
