Huawei HG232f User Manual

HG232f 300Mbps Wireless Router
User Guide
2 Hardware Installation
2-3
2.3.2 Installing the Router on an ADSL Broadband Network
On the ADSL broadband network, the ADSL modem provides an Ethernet interface used
to connect a computer to the Internet.
Figure 2-2 Shows the cable connections of an ADSL broadband network after the router
is installed on the network
1. Power adapter of the router
2. Router
3. Power adapter of the ADSL modem
4. Desktop computer
5. ADSL modem
6. Telephone
7. Splitter
8. Telephone line interface on the wall
2.3.3 Installing the Router on a CATV Broadband Network
On C AT V broadband network, the cable modem provides an Ethernet interface used to
connect a computer to the Internet.

Huawei HG232f Specifications

General

Brand	Huawei
Model	HG232f
Category	Wireless Router
Language	English
