Huawei iSitePower-M - LED Indicators and System Networking

20
Capacity Expansion Scenario
• In capacity expansion scenarios, cascading cables at the lower part must be routed from the
rear of the product.
• Cables outside the device must be routed through cable pipes.
FusionSolar Smart PV
Management System
Installing Power Module Communications Cable
6.7
Router
Locking cap
Waterproof
rubber plug
Waterproof gland
Install the waterproof
rubber plug for the hole
with no cable routed.
Build-out
resistor
