Huawei NE40E-X2 User Manual

Table 3-9 Attributes of the interfaces on the 8-Port 100/1000Base-X-SFP High-speed Interface
Card A (HIC, Supporting 1588v2)
Attribute Value
Connector LC/PC
Interface attributes Determined by the selected SFP optical module
Working mode Full-duplex
Standard
compliance
IEEE 802.3-2002
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
Table 3-10 Attributes of the 100 M SFP optical module
Attribute Value
Maximum
transmission
distance
2 km ( 1.24
mi. )
15 km ( 9.32
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center wavelength 1310 nm 1310 nm 1310 nm 1550 nm
Minimum output
power
-19.0 dBm -15.0 dBm -5.0 dBm -5.0 dBm
Maximum output
power
-14.0 dBm -8.0 dBm 0 dBm 0 dBm
Receiver sensitivity -30.0 dBm -31.0 dBm -37.0 dBm -37.0 dBm
Overload optical
power
-14.0 dBm -8.0 dBm -10.0 dBm -10.0 dBm
Fiber type Multimode Single-mode Single-mode Single-mode
Table 3-11 Attributes of the 1000M SFP optical module
Attribute
Value
Transmission
Distance
0.5 km
( 0.31
mi. )
10 km
( 6.21
mi. )
40 km
( 24.86
mi. )
40 km
( 24.86
mi. )
80 km
( 49.71
mi. )
100 km
( 62.14
mi. )
Center wavelength 850 nm 1310 nm 1310 nm 1550 nm 1550 nm 1550 nm
Minimum output
power
-9.5 dBm -9.5 dBm -4.5 dBm -4.0 dBm -2.0
dBm
0 dBm
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 3 Boards
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
49
