Attribute Description
Nominal bit rate 2048 kbit/s
Interface
impedance
120 ohm
Interface code HDB3
Pulse waveform of
the output
interface
Compliant with ITU-T G0.703
Attenuation (dB)
of the input
interface at a point
with the frequency
of 1024 kHz
0 to 6
Immunity of the
input interface
Compliant with ITU-T G0.703
Input jitter
tolerance
Compliant with ITU-T G.823
Output jitter Compliant with ITU-T G.823
Technical Specifications
Table 3-30 shows the technical specifications of the 16-Port E1(120ohm) Flexible Interface
Card (FIC).
Table 3-30 Technical specifications of the 16-Port E1(120ohm) Flexible Interface Card (FIC)
Specification
Description
Silkscreen print 16xE1-120
Typical power
consumption
15 W
Heat dissipation 49 BTU/hour
Weight 0.45 kg ( 0.99 lb )
Dimensions (W x D x H) 194 mm x 226 mm x 20 mm ( 7.64 in. x 8.90 in. x 0.79 in. )
Connector type Anea 96, 120 ohm
Earliest software version V600R002C03
Product Specifications
Table 3-31 lists the specifications of the 16-Port E1(120ohm) Flexible Interface Card (FIC).
