Huawei NE40E-X2 User Manual

Table 3-38 Description of the indicators on the 1-Port Channelized OC3c/STM1c POS-SFP
Flexible Interface Card (FIC)
Indicator Description
STAT If the indicator is steady green, it indicates that the1-Port Channelized
OC3c/STM1c POS-SFP Flexible Interface Card (FIC) works normally.
If the indicator is off, it indicates that the 1-Port Channelized OC3c/
STM1c POS-SFP Flexible Interface Card (FIC) is not powered on or
fails to be registered.
If the indicator is steady red, it indicates that the hardware of the 1-Port
Channelized OC3c/STM1c POS-SFP Flexible Interface Card (FIC)is
faulty.
If the indicator is steady yellow, it indicates that logic is not loaded to
the 1-Port Channelized OC3c/STM1c POS-SFP Flexible Interface Card
(FIC).
LOS1/LOS2
If the indicator is steady green, it indicates that optical signals are
normal.
If the indicator is steady red, it indicates that optical signals are lost.
If the indicator is off, it indicates that the optical module is not installed.
Interface Attributes
Table 3-39 lists the interface attributes of the 1-Port Channelized OC3c/STM1c POS-SFP
Flexible Interface Card (FIC).
Table 3-39 Interface attributes of the 1-Port Channelized OC3c/STM1c POS-SFP Flexible
Interface Card (FIC)
Attribute
Description
Connector type LC/PC
Optical interface
attribute
Determined by the selected SFP optical module (for attributes of the SFP
optical module, see Table 3-40)
Working mode Full duplex
Link protocol ML-PPP
Network protocols IP
Table 3-40 Attributes of the 155-Mbit/s SFP optical module
Attribute
Description
Transmission
distance
2 km ( 1.24 mi. ) 15 km ( 9.32
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 3 Boards
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
70
