Huawei OptiX OSN 8800 User Manual

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
89
Table 4-59 Maximum AC power consumption of the universal platform subrack
Item
Value
Maximum subrack power consumption
a
220 V (Input voltage) : 1800 W
110 V (Input voltage) : 1400 W
a: The maximum subrack power consumption refers to the theoretical power consumption
obtained when boards with the highest power consumption are installed in every slot on the
subrack.
Table 4-60 describes the power consumption of the universal platform subrack with typical
configurations.
Table 4-60 Power consumption of the universal platform subrack with typical configurations
Unit Name
Typical
Power
Consumpt
ion (W)
a
Maximum
Power
Consump
tion (W)
a
Remarks
Elect
rical
relay
subra
ck
Subra
ck 1
942
1109
8 x NO2, 2 x APIU, 1 x EFI, 2 x SCC, and
fan tray assembly
Subra
ck 2
1025
1221
8 x TN58NS4 (SDFEC2), 2 x APIU, 1 x
EFI, 2 x SCC, and fan tray assembly
OTM
subra
ck
Subra
ck 1
841
1021
4 x TN17LTX, 2 x APIU, 1 x EFI, 2 x SCC,
and fan tray assembly
Subra
ck 2
781
953
4 x TN17LSC, 2 x APIU, 1 x EFI, 2 x SCC,
and fan tray assembly
Subra
ck 3
319
510
1 x M40V, 1 x D40, 1 x OAU101, 1 x
OBU103, 1 x FIU, 1 x SC1, 2 x APIU, 1 x
EFI, 2 x SCC, and fan tray assembly
OLA subrack
285
459
2 x OAU101, 2 x FIU, 1 x SC2, 2 x APIU, 1
x EFI, 2 x SCC, fan tray assembly
ROADM
subrack (4 x
dimensions)
b
313
491
1 x WSMD4, 1 x DAS1, 1 x M40, 1 x D40,
2 x APIU, 1 x EFI, and fan tray assembly
OTM cabinet
1941
2485
OTM subrack1, OTM subrack2, and OTM
subrack3
a: Indicates that the power consumption of the subrack and cabinet is the value in a certain
configuration. The value is for reference only. The actual power consumption of the chassis
and cabinet is calculation based on the power consumption of each module. The maximum
power consumption is the power consumed by the board when it works normally under the
highest ambient temperature.
b: Subrack 1 and subrack 2 are used as subracks in the line dimensions at a four-dimension
ROADM station; subrack 3 and subrack 4 are used as subracks for adding/dropping local
services. Service boards can be configured in another subrack.
