Installing Ground Cables
Installing PDU Ground Cables
b
Installing Cabinet Ground Cables
a
•Connect the cabinet ground cable to the
ground bar in the equipment room.
NOTE
Ground bar in the
equipment room
Ground cable
•Connect the PDU ground cables to the
ground screws on one side of the cabinet.
NOTE
