Assembling Connectors
•For the method of assembling connectors for elliptic waveguides,
see the delivered connector assembling guide.
•Before hoisting an elliptical waveguide, assemble the antenna-
side connector.
•After routing an elliptical waveguide indoors, assemble the indoor
connector.
Installing an Elliptical Waveguide
•When assembling a connector or cutting an elliptical waveguide, be sure to clear scraps in the waveguide.
NOTE
CAUTION
34
When assembling an elliptical waveguide connector, ensure that the connector is intact and all screws are tightened.
The elliptical waveguide connector is over
hammered, the surface of the elliptical waveguide
connector is uneven and has cracks.
Elliptical waveguide connector with
good quality
