Quidway S5600 Series Ethernet Switches Chapter 1
Product Overview
Huawei Technologies Proprietary
1-6
LED Mark Status Description
POST
running
Blinking
green
The POST ID of the in-process
test is displayed:
POST failed
Blinking
red
The POST ID of the failed test
blinks.
Software
downloading
Blinking
green
A light bar rotates clockwise
around the display during the
downloading procedure.
Fan failed Solid red
An “F” is displayed.
Over
temperature
alarm
Solid red
A “t” is displayed.
Speed and
duplex mode
Solid
green
UNIT ID in the fabric; or “1” for a
standalone unit is displayed.
7-segment
digitron
display
Unit
PoE mode
Solid
green
The utilization of the power
supply is displayed.
0 - 20%
21 - 40%
41 - 60%
61 - 80%
81 - 100%
