Huawei Quidway S5600 Series Installation Manual

Installation Manual
Quidway S5600 Series Ethernet Switches Chapter 1
Product Overview
Huawei Technologies Proprietary
1-11
Item Description
Baud rate 9600 bps (default), auto-negotiation is supported
Services
Connection to an ASCII terminal
Connection to the serial port of a local terminal (a PC for
example) or a remote terminal (through a pair of modems)
running terminal emulation software
IV. Attributes of 1000 Mbps SFP port
The S5624P/S5624P-PWR provides four SFP Combo ports on its front panel, each one
corresponding to a 10/100/1000Base-T auto-negotiation Ethernet port. For each
corresponding pair, only one port can be used at the same time. The number of the SFP
Combo ports and the type of the SFP module are optional. For the relationship between
the Combo ports and the Ethernet ports, refer to
Table 1-1
The S5624F provides 24 × 1000 Mbps SFP ports on its front panel.
SFP modules allow for great flexibility in networking because they are hot swappable
and user configurable.
The following table lists the available SFP modules that you can select as required:
Table 1-5 Specifications of 1000 Mbps SFP port cable
SFP module
Central
wavelen
gth
Connec
tor
Fiber
specification
Maximum
transmission
distance
50/125 µm
multi-mode
optical fiber
550 m (1804.5
ft.)
1000BASE-SX-SFP 850 nm
62.5/125 µm
multi-mode
optical fiber
275 m (902.2
ft.)
1000BASE-LX-SFP 10 km (6.2 mi)
1000BASE-LH-SFP
1310 nm
30 km (18.6 mi)
1000BASE-ZX-LR-SFP 40 km (24.9 mi)
1000BASE-ZX-VR-SFP
1550 nm
LC
Single-mode
fiber
70 km (43.5 mi)
1000BASE-T-AN-SFP
—
RJ-45
Category-5
twisted pair
cable
100 m (328 ft)
