Huawei Quidway S5600 Series Installation Manual

Installation Manual
Quidway S5600 Series Ethernet Switches Chapter 1
Product Overview
Huawei Technologies Proprietary
1-10
LED Mark Status Description
Green
The port is operating at 1000
Mbps. The LED blinks quickly
when the port is receiving or
sending data.
Yellow
The port is operating at 10/100
Mbps. The LED blinks quickly
when the port is receiving or
sending data.
Blinking
yellow
(at 3 Hz)
The port fails the POST.
Speed mode
OFF The port is not connected.
Green
The port is operating in full
duplex mode. The LED blinks
quickly when the port is
receiving or sending data.
Yellow
The port is operating in half
duplex mode. The LED blinks
quickly when the port is
receiving or sending data.
Blinking
Yellow
(3 Hz)
The port fails the POST.
RJ-45
Combo
port mode
LED
Duplex mode
OFF The port is not connected.
Green
The port is operating at 1000
Mbps. The LED blinks quickly
when the port is receiving or
sending data.
Blinking
yellow (3
Hz)
The port fails the POST.
1000Base
SFP
optical
port status
LED
port status
LED
OFF The port is not connected.
III. Console port
The S5624P/S5624P-PWR/S5624F provides an EIA/TIA-232-compliant Console port,
which enables you to configure the switch from the local or remote site.
Table 1-4 Attributes of the Console port
Item Description
Connector RJ-45
Standard EIA/TIA-232
