Figure 7-5 Process of installing RRU cables
7.4 RRU Cable List
This section describes RRU cable connections.
Table 7-1 lists RRU cables.
Table 7-1 RRU cables
Cable
One End The Other End
Connector Installation
Position
Connector Installation
Position
RRU PGND
Cable
OT terminal
(M6, 16 mm
2
[0.025 in.
2
])
Ground
terminal on the
RRU
OT terminal (M8,
16 mm
2
[0.025 in.
2
])
Ground terminal
on the ground bar
RRU Power
Cable
Easy power
receptacle
(pressfit type)
connector
NEG(-) and
RTN(+) ports
on the RRU
Easy power
receptacle
(pressfit type)
connector
RRU0 to RRU5
on the EPS
RRU3232
