– To avoid inhaling dust and prevent dust from falling into your eyes, wear
safety goggles and an anti-dust mask when drilling holes.
– Use a vacuum cleaner to clear the dust inside and around each hole. If the
distance between two holes is incorrect, mark and drill holes again.
– Level the head of the expansion sleeve with the concrete wall after
removing the nut, spring washer, and at washer. Otherwise, the mounting
bracket will not be securely installed on the wall.
– The indoor and outdoor installation methods are the same. The wall must
meet the load-bearing requirements.
Figure 4-11 Installing the mounting bracket (plywood)
Figure 4-12 Installing the mounting bracket (solid brick concrete wall)
Step 4 Install and secure the SUN2000 onto the mounting bracket
SUN2000-4.95KTL-JPL1
User Manual 4 Installation
Issue 05 (2023-02-17) Copyright © Huawei Technologies Co., Ltd. 33
