Huawei SUN2000-5KTL-L1 User Manual

F AI Energy Management Assistant
(EMMA)
The AI Energy Management Assistant (EMMA) provides intelligent energy
scheduling and management functions. Based on big data analysis, it accurately
predicts the power generation and consumption curves of households, and
intelligently stores, purchases, and sells electricity to achieve optimal system
performance, improve the utilization rate of green power, and maximize
nancial
benets.
● Method 1: FusionSolar Smart PV Management System WebUI
When the system determines that the plant meets the conditions for enabling
the EMMA function, the EMMA dialog box is displayed. You can enable the
EMMA function as prompted. If you select Not Now, you can click
next to EMMA and enable the EMMA function as prompted.
● Method 2: FusionSolar app
On the Overview screen, if the system determines that the plant meets the
conditions for enabling the EMMA function, is displayed in the
energy
ow diagram. You can tap this icon to enable the EMMA function.
Alternatively, tap ... in the upper right corner and then tap EMMA.
NO TE
● Only owners have the permission to enable the EMMA function. After the EMMA
function is enabled, owners and installers can view the relevant revenue and energy
forecast and analysis.
● For details, see the user manuals of the FusionSolar Smart PV Management System and
FusionSolar app.
SUN2000-(2KTL-6KTL)-L1
User Manual F AI Energy Management Assistant (EMMA)
Issue 10 (2023-02-13) Copyright © Huawei Technologies Co., Ltd. 126

Huawei SUN2000-5KTL-L1 Specifications

General

Model	SUN2000-5KTL-L1
Max. Efficiency	98.4%
Rated AC Output Power	5000 W
Operating Temperature Range	-25°C to +60°C
Topology	Transformerless
Max. apparent AC power	5500 VA
Max. input voltage	600 V
Number of MPPT trackers	2
Max. short-circuit current per MPPT	15 A
Protection degree	IP65
Max. Input Power	7500 W
Output Frequency	50 Hz / 60 Hz
Cooling Method	Natural Convection
Nominal AC voltage	230 V
AC voltage range	180 V - 280 V
Rated Output Voltage	230 V
