Huawei SUN2000-5KTL-L1 User Manual

5 Electrical Connection
5.1 Precautions
D ANGER
When exposed to sunlight, the PV arrays supply DC voltage to the SUN2000.
Before connecting cables, ensure that the two DC switches on the SUN2000 are
OFF. Otherwise, the high voltage of the SUN2000 may result in electric shocks.
D ANGER
● The site must be equipped with qualied re suppression facilities, such as re
sand and carbon dioxide re extinguishers.
● Wear insulated gloves and use insulated tools to prevent electric shocks or
short circuits.
WARNING
● The equipment damage caused by incorrect cable connections is beyond the
warranty scope.
● Only
certied electrician can perform electrical terminations.
● Wear proper PPE at all time when terminating cables.
● To prevent poor cable connection due to overstress, it is recommended that the
cables be bent and reserved, and then connected to the appropriate ports.
SUN2000-(2KTL-6KTL)-L1
User Manual 5 Electrical Connection
Issue 10 (2023-02-13) Copyright © Huawei Technologies Co., Ltd. 37

Huawei SUN2000-5KTL-L1 Specifications

General

Model	SUN2000-5KTL-L1
Max. Efficiency	98.4%
Rated AC Output Power	5000 W
Operating Temperature Range	-25°C to +60°C
Topology	Transformerless
Max. apparent AC power	5500 VA
Max. input voltage	600 V
Number of MPPT trackers	2
Max. short-circuit current per MPPT	15 A
Protection degree	IP65
Max. Input Power	7500 W
Output Frequency	50 Hz / 60 Hz
Cooling Method	Natural Convection
Nominal AC voltage	230 V
AC voltage range	180 V - 280 V
Rated Output Voltage	230 V
