NO TE
There are two types of Smart Dongle:
● For details about how to use the WLAN-FE Smart Dongle SDongleA-05, see the
SDongleA-05 Quick Guide (WLAN-FE) . You can also scan the QR code to obtain
the document.
● For details about how to use the 4G Smart Dongle SDongleA-03, see the
SDongleA-03 Quick Guide (4G) . You can also scan the QR code to obtain the
document.
The quick guide is delivered with the Smart Dongle.
5.5 Installing a WLAN Antenna
Procedure
Step 1 Remove the watertight cap from the ANT port.
Step 2 Install the washer to the ANT port on the chassis.
Step 3 Install the WLAN antenna.
NO TICE
Ensure that the WLAN antenna is installed securely.
SUN2000-(2KTL-6KTL)-L1
User Manual 5 Electrical Connection
Issue 10 (2023-02-13) Copyright © Huawei Technologies Co., Ltd. 47

Huawei SUN2000-5KTL-L1 Specifications

General

Model	SUN2000-5KTL-L1
Max. Efficiency	98.4%
Rated AC Output Power	5000 W
Operating Temperature Range	-25°C to +60°C
Topology	Transformerless
Max. apparent AC power	5500 VA
Max. input voltage	600 V
Number of MPPT trackers	2
Max. short-circuit current per MPPT	15 A
Protection degree	IP65
Max. Input Power	7500 W
Output Frequency	50 Hz / 60 Hz
Cooling Method	Natural Convection
Nominal AC voltage	230 V
AC voltage range	180 V - 280 V
Rated Output Voltage	230 V
