Step 2 Connect the signal cable to the COM port.
Figure 5-31 Securing the signal cable connector
----End
5.8.3 Connecting an RS485 Communications Cable (Between a
Power Meter and a Battery)
Procedure
Step 1 Connect the signal cable to the signal cable connector.
Figure 5-32 Installing the cable
Step 2 Connect the signal cable connector to the COM port.
