Huawei SUN2000-75KTL Series User Manual

(1) DC input terminals (2) RS485 port
(3) Ground point on the enclosure (4) AC terminal block (3-pin)
Figure 2-11 Wiring port of 4-pin models (SUN2000-110KTL-M0,
SUN2000-100KTL-M0, SUN2000-100KTL-M1, SUN2000-100KTL-INM0 and
SUN2000-75KTL-M1)
(1) DC input terminals (2) RS485 port
(3) Ground point on the enclosure (4) AC terminal block (4-pin)
2.4.2 Indicator Status
Figure 2-12 Indicator
SUN2000-(75KTL, 100KTL, 110KTL, 125KTL) Series
User Manual 2 Overview
Issue 15 (2023-01-31) Copyright © Huawei Technologies Co., Ltd. 22

Huawei SUN2000-75KTL Series Specifications

General

Brand	Huawei
Model	SUN2000-75KTL Series
Category	Inverter
Language	English
