In the CloudVC on-premises networking scheme, the endpoint TE30 can hold multipoint
conferences using its built-in MCU, without any intervention of the SMC2.0 or MCU. The
built-in MCU makes conference rooms of small- and medium-sized enterprises video-
enabled. Figure 3-2 shows the built-in MCU-based network of the endpoint.
Figure 3-2 Built-in MCU-based network
The network is described as follows:
l After having the built-in MCU enabled, the endpoint TE30 can hold both encrypted and
unencrypted conferences.
– An unencrypted conference can hold a maximum of three 576p 30 fps HD video
sites and three audio sites, besides the site that initiates the conference. Each video
site occupies 1.5 Mbit/s bandwidth. The total bandwidth occupied by the conference
cannot exceed 4.5 Mbit/s.
– An encrypted conference can hold a maximum of three 576p 30 fps HD video sites,
besides the site that initiates the conference. Each video site occupies 1 Mbit/s
bandwidth. The total bandwidth occupied by the conference cannot exceed 3
Mbit/s.
l SD and HD video sites and audio-only sites of the H.323 or SIP type can join
conferences on this network.
NOTE
Audio-only sites can join conferences using IP phones only when the SC is deployed on the
network.
l This network supports presentation sharing through the H.239 protocol, as well as
simultaneous video and presentation sharing through the Binary Floor Control Protocol
(BFCP).
TE30 Videoconferencing Endpoint
Product Overview
3 Application Scenarios
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 6
