HUAWEI TE80 Videoconferencing Endpoint
Administrator Guide
4 Display Device and Camera
Issue 02 (2014-03-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
42
Parameter
Description
Setting
displays.

When this parameter is disabled, the
outputs from the Auxiliary output
port and Main output interface are
the same.

When this parameter is enabled, the
Auxiliary output port is used to
display the local or remote
presentation and display a black screen
if no presentation source is connected.
Disable this parameter
when only one display
device is connected to the
endpoint.
Step 2 Select Save.
Step 3 Choose Advanced > Settings > Video > Video Output. Set the advanced video output
parameters described in Table 4-9.
Table 4-7 Advanced video output parameters
Parameter
Description
Setting
Name
Specifies the output port name to help
you identify ports during a conference.

The default value for the
1 MAIN OUT port is 1
MAIN OUT.

The default value for the
2 PC OUT port (only
TE80) is 2 PC OUT.

The default value for the
3 DVR OUT port (only
TE80) is 3 DVR OUT.

The default value for the
4 3G-SDI OUT port
(only TE80) is 4
3G-SDI OUT.

The default value for the
2 SD OUT port (only
TE80) is 2 SD OUT.
Output mode
Specifies the format for the video
received by the display.
Output modes vary according to video
output ports. For details, see Table 4-4,
Table 4-5, and Table 4-6.
Default values:

1 MAIN OUT port:
DVI if the TE80 is used.

2 PC OUT port (only for
the TE80): DVI

3 DVR OUT port (only
for the TE80): DVI

4 3G-SDI OUT port
(only for the TE60 and
TE80): SDI

2 SD OUT port (only for
