TP48200A-DX12A1 Telecom Power
User Manual
3 Components
Copyright © Huawei Technologies Co., Ltd.
21
Figure 3-3 AC box without cover on TP48200A-DX12A1 (DC2)
(1) German standard maintenance
socket and protective circuit
breaker
(2) AC light power
terminals and time
relay
(3) AC input circuit breaker
and terminals
(4) PE terminal
(5) AC output circuit
breaker and terminal
(6) Emergency AC input
circuit breaker and
terminals
Figure 3-4 DC output box on TP48200A-DX12A1 (DC2)
(1) BLVD circuit breakers
