A.3 EMC Specifications
Table A-3 EMC specifications
Item
Specifications
Electromagnetic
interference (EMI)
Conducted emission (CE)
AC port: EN300386 Class B
DC port: EN300386 Class A
Signal port: EN300386 Class B
Radiated emission (RE)
Class B, EN300386
Harmonic current
IEC61000-3-12
Voltage fluctuation and flicker
IEC61000-3-11
Electromagnetic
susceptibility (EMS)
ESD
IEC61000-4-2 (criterion B)
Contact discharge: 6 kV; air discharge: 8 kV
Electrical fast transient (EFT)
IEC61000-4-4 (criterion B)
AC power port: 2 kV; DC power port: 1 kV;
signal port: 1 kV
Radiated susceptibility (RS)
IEC61000-4-3 (criterion A)
10 V/m
Conducted susceptibility (CS)
IEC6100-4-6 (criterion A)
Power port: 10 V; signal port: 3 V
Surge immunity
IEC61000-4-5 (criterion B)
AC power port: differential mode: 2 kV (8/20
µs); common mode: 4 kV (8/20 µs)
DC power port: differential mode: 2 kV (8/20
µs); common mode: 4 kV (8/20 µs)
Signal port: differential mode: 0.5 kV; common
mode: 1 kV
Voltage dips immunity (DIP)
EN61000-4-11
A.4 Cabinet Specifications
Table A-4 Cabinet specifications
Item
Specifications
Cabinet dimensions (H x W x D)

TP48200A-DX12A1: 1200 mm x 650 mm x 650 mm

Base: 150 mm x 650 mm x 650 mm
Cabinet weight
≤ 115 kg (excluding rectifiers and batteries)
Protection level
IP55
