Silk Screen Signal Port Pin Function
VTEM2 Port for detecting temperature 2
l Pin 1 is for the +12 V power
supply.
l Pin 2 is for the signal cable.
JTD1-JTD7 Port for digital parameter input
l Pin 1 and pin 2 are for +12 V
power supply.
l Pin 3 is for the signal cable.
l Pin 4 is for grounding.
SMOKE Smoke sensor port
l Pin 1 is for the signal cable.
l Pin 2 is for +12 V power supply.
WATER Water sensor port
l Pin 1 is for +12 V power supply.
l Pin 2 is for the signal cable.
l Pin 3 is for grounding.
JTM1 Door status sensor port
l Pin 1 is for the signal cable.
l Pin 2 is for +12 V power supply.
JTP1 Sensor port on the MDF
l Pin 1 is for the signal cable.
l Pin 2 is reserved.
JK1/JK2 Alarm dry contact output port The maximum voltage is 60 V DC
and the maximum load current is
500 mA.
JAC1/JAC2 Alarm dry contact output port The maximum voltage is 60 V DC
and the maximum load current is
500 mA.
JKM1-JKM4 Alarm dry contact output port The maximum voltage is 60 V DC
and the maximum load current is
500 mA.
CAB_E-LABEL Cabinet electronic label port
l Pin 1 is for +5 V power supply.
l Pin 2 is for the clock cable.
l Pin 3 is for the digital cable.
l Pin 4 is for grounding.
Parameter
Table 8-9 lists the specifications of the MUE02A sensor transfer box.
Table 8-9 Specifications of the MUE02A sensor transfer box
Parameter
Specifications
Dimensions (H x W x D) 31 mm x 140 mm x 96 mm
