Table 9-20 Settings of SW1 on the FCBA board
SW1-1 SW1-2 SW1-3 SW1-4
J1 J2 J3 J4
OFF OFF OFF ON
Table 9-21 describes the functions of the DIP switches on SW2.
Table 9-21 Functions of SW2 on the FCBA board
DIP Switch Function
1, 2, 3 Set the subnode addresses. For details, see Table 9-22.
4 Sets the baud rate of the serial port. For details, see Table 9-23.
Table 9-22 Settings of SW2-1 to SW2-3 on the FCBA board
SW2-3
SW2-2 SW2-1 Subnode Address
ON ON ON 0
ON ON OFF 1
ON OFF ON 2
ON OFF OFF 3
OFF ON ON 4
OFF ON OFF 5
OFF OFF ON 6
OFF OFF OFF 7
Table 9-23 Settings of SW2-4 on the FCBA board
SW2-4
Indication Default Setting
ON The baud rate of the serial port is 19200 bit/
s.
ON
OFF The baud rate of the serial port is 9600 bit/
s.
