Mapping Between Monitoring Parameters and Device Ports
Table 5-7 describes the mapping between the monitoring parameters displayed on the host and
the ports on the ESCM.
Table 5-7 Mapping between the monitoring parameters displayed on the host and the ports on
the ESCM
Monitoring
Parameter
Displayed on the
Host
Device Port Application in the M200 Cabinet
Temperature Temperature Temperature
Input_-48V_0 Voltage Voltage
Analog 3 JTA1 Humidity
Analog 4 JTA2 Not connected by default, used to add a user-
defined monitoring analog parameter
Wiring JTP1 (MDF) MDF
Door0 JTM1 (door status) Door status sensor
Digital 2 JTD1 Not connected by default, used to add a user-
defined monitoring digital parameter
Digital 3 JTD2 Not connected by default, used to add a user-
defined monitoring digital parameter
Digital 4 JTD3 Not connected by default, used to add a user-
defined monitoring digital parameter
Digital 5 JTD4 Not connected by default, used to add a user-
defined monitoring digital parameter
Digital 6 JTD5 Not connected by default, used to add a user-
defined monitoring digital parameter
Digital 7 JTD6 Not connected by default, used to add a user-
defined monitoring digital parameter
Digital 8 JTD7 Not connected by default, used to add a user-
defined monitoring digital parameter
Digital 9 JTS1 (water) Not connected by default, used to add a user-
defined monitoring digital parameter
NOTE
Before adding a user-defined analog or monitoring digital parameter, make sure that the port corresponding
to this analog or monitoring digital parameter is properly connected with an environment monitoring cable.
