Huawei UPS5000-A-30KTTL User Manual

Figure 2-9 Front view (30 kVA/40 kVA)
(A) UPS5000-A-30KTTL (BOM numbers:
02291114 and 02291235)/UPS5000-A-40KTTL
(BOM numbers: 02291115 and 02291236)
(B) UPS5000-A-30KTTL (BOM numbers:
02290371 and 02311GNW)/UPS5000-
A-40KTTL (BOM numbers: 02290372 and
02311GNX)
(1) Bypass unit 1 (BOM number: 02313XPD) (2) Power unit
(3) Bypass unit 2 (BOM number: 02310SEN)
Rear View
Figure 2-10 Rear view (30 kVA/40 kVA)
(1) Control ports
(2) Maintenance bypass switch (3) UPS output terminals
(under the cover)
(4) Battery wiring terminals
(under the cover)
(5) UPS bypass input terminals
(under the cover)
(6) UPS mains input terminals
(under the cover)
UPS5000-A-(30 kVA-120 kVA)
User Manual 2 Product Overview
Issue 17 (2024-02-21) Copyright © Huawei Digital Power Technologies Co., Ltd. 29
