Rear View
Figure 2-19 Rear view (120 kVA)
(1) Control ports (2) PDU
2.5 Component Description
2.5.1 Power Unit
The layout of the power unit varies depending on the chassis. The following gure uses the
30 kVA UPS as an example.
UPS5000-A-(30 kVA-120 kVA)
