SR05-D1A3-PV manual v1801 67/83
Table 9.1.1 Specifications for SR05 cable replacement and extension
General replacement
please order a new cable with connector at Hukseflux
General cable extension
please order an extension cable with connector pairs at Hukseflux
Connectors used
chassis: M12-A straight male connector, male thread, 5-pole
manufacturer: Binder
cable: M12-A straight female connector, female thread, 5-pole
manufacturer: Binder
The shield is electrically connected to the connector housing
Cable
5-wire, shielded
manufacturer: Binder
Length
cables should be kept as short as possible; total cable length should be
less than 40 m
Outer sheath
with specifications for outdoor use
(for good stability in outdoor applications)
