235
Specifications
S
HELIX 5 SONAR G2
Control Head
Display Size (diagonal) ................................................................................... 5 inches (127 mm)
Pixel Matrix .............................................................................................. WVGA 480V x 800H
Display Type ...................................................................................................... TFT Color
Backlight .............................................................................................................. LED
Communication ................................................................................................. NMEA 0183
Power Input ................................................................................................... 10 to 20 VDC
Current Draw ....................................................................................................... 650 mA
IPX Rating ................................................................. IPX7 Waterproof/Submersible @ 1 m for 30 minutes
DualBeam PLUS Transducer
XNT 9 20 T (includes built-in temperature probe)
Operating Frequency ........................................................................................ 200 kHz, 83 kHz
Depth Capability ............................................................................................ 1500 ft (457 m)
Area of Coverage ............................................................... 60°@-10 dB in 83 kHz, 20°@-10 dB in 200 kHz
Power Output (MAX) .............................................................. 500 Watts (RMS), 4000 Watts (Peak to Peak)
NOTE: Humminbird verifies maximum stated depth in saltwater conditions, but actual depth performance may vary due to
transducer installation, water type, thermal layers, bottom composition, and slope.
NOTE: Product specifications and features are subject to change without notice.
