INSTALLATION
5
■ Use a level to check that the mounting surface is level. Shim the brackets, if necessary (use
the top tab that was removed from the brackets).
■ Use a
3
/
32
" drill bit to drill holes for the mounting screws.
Important: Use drywall anchors when mounting into drywall.
■ Attach the installation brackets using the screws provided.
Important: Do not overtighten the screws. Check to ensure the lever can be moved
easily side to side. If the lever is not moving easily, loosen the screws
1
/
8
of a turn
increments until it can be moved easily.
Important: The front edges of the installation brackets must be level and aligned to
eachother.
Proceed to “Attach the Back Cover (Optional for Inside or End Mounts)” on page 7,
or proceed to “Install the Shading” on page 8.
Mount the Installation Brackets — Outside Mount
■ Center the headrail over the window opening at the desired height. Use a pencil to lightly
mark each end of the headrail.
➤ Alternatively, measure the width of the headrail and use that width to mark the headrail
end points over the window opening.
■ Mark 2"– 3" from each end of theheadrail, for bracket location.
➤ If more than two installation brackets came with your order, space additional bracket(s)
evenly between the two end brackets and mark their location. Mount into studs
whenever possible.
■ Two-On-One Headrail Shadings. Two additional installation brackets should be placed on
each side of the panel split.
Window Opening
Space EvenlySpace Evenly
2" – 3"
2" – 3"
To Next Page
