Hunter H33 - Page 109

Hu
nt
e
r
33
• D
C
Electric
7.1
3
FLUORESCENTS
RECESSED LIGHTS
DOME LIGHTS
SWIVEL LIGHTS
NEGATIVE BUS BAR
EXAMPLE LIGHT WIRING (PARALLEL CIRCUIT)
POS./NEG. LEADS TO LIGHT
LIGHT
YELLOW
BLUE/WHITE
TO NEXT LIGHT
EACH CIRCUIT IN PARALLEL, BLUE (LOAD TO BREAKER) AND YELLOW NEGATIVE TO NEGATIVE BUS BAR (SEE EX.)
PANEL BRKR.
FROM BATT.
CABIN LIGHTS 1
FROM BATT.
BLUE
YELLOW
BLUE
YELLOW
BLUE
YELLOW
12 Volt Interior Lihgting Diagram
gg g
