Hunter H33 - Hunter 33 Conventional Standing Rigging

Hu
nt
e
r
33
• Sails and Ri
gg
in
g
12.1
0
ITEM QTY FITTINGS
1 D3 2 1/4" 6mm T-TERMINAL 308-324 12ft 4" 3760 mm
FORK 308-417
2 V2 2 1/4" 6mm EYE 308-362 11ft 5" 3480 mm
EYE 308-362
3 D2 2 3/16" 5mm STEMBALL 308-552 11 FT 3 5/8" 3445 mm
CUP 306-572
CUP 306-573
STD/FRK TB 174-472-06
4 RD2 2 5/32" 4 mm FORK 308-312-01 10 FT 10 3/8" 3310 mm
STD/T TB 174-472-21
5 V1 2 9/32" 7 mm FORK 308-315-01 13ft 1/2" 3975 mm
STD/TGLE TB 174-324-10
6 D1 2 1/4" 6 mm STEMBALL 308-553 13ft 10 1/8" 4220 mm
CUP 306-573
STD/TGLE TB 174-324-09
7 RD1 2 5/32" 4 mm FORK 308-312-01 8FT 4 3/4" 2560 mm
STD/T TB 174-472-21
8 F0RESTAY 1 1/4" 6 mm FURLEX 106-12 38 ft. 2 1/2" 11645 mm
027-019-73
HUNTER 33 CONVENTIONAL
STANDING RIGGING
WIRE SIZE CP / EOS
3. MEASURE T-TERMINALS &STEMBALLS FROM TOP OF FITTING.
1. CP = CENTER PIN; EOS = END OF STUD
2. LENGTHS DO NOT
INCLUDE SPREADER TIP LINKAGE.
SELDEN MAST SRIG-0103
