Hunter H33 - Page 147

Hu
nt
e
r
33
• Waste and Sanitation S
y
stems
1
0
.1
3
3/4” (1.9cm) HOSE
1 1/2” (3.8cm) HOSE
DECK PUMP OUT FITTING
WASTE TANK VENT (ON DECK)
3/4” (1.9cm) HOSE
ANTI - SIPHON VALVE
TOILET
3/4” (1.9cm) THRU - HULL WITH BALL VALVE (HEAD PICKUP)
MACERATOR PUMP
1” (2.5cm) HOSE
1” (2.5cm) THRU - HULL WITH BALL VALVE (DISCHARGE)
Waste Water System ( Black Water)
y( )
