CONNECTING AC POWER
Indoor cabinet
Route transformer cable through the hole on the bottom le side of the controller and
connect one yellow wire to each of the screws marked 24AC and the green wire to GND.
Note: The indoor Pro-HC is not water or weather resistant, and must be installed
indoors or in a protected area. This device is not intended for use by young children.
Never let children play with this device.
Transformer
