Choose the hanging system that most closely
resembles the one used by your fan and place the
receiver as shown.
4
Note: If your canopy is crowded with excess wire, you may wish to cut
the excess fan wires. Leave a minimum of 8 inches remaining. Strip the
fan lead wires 1/2 inch. Place remaining excess wire into the ceiling
electrical box. The bracket and fan must remain properly grounded.
If the fan is installed on an angled ceiling and you need assistance with
installation, please call 1-888-830-1326.
For low prole fans, secure the receiver
to the ceiling bracket with a cable tie.
installation (continued)
WARNING: This receiver cannot be installed in conjunction with any other receiver
or hard-wired wall control. Doing so will void your warranty.
Hanging System 1 Hanging System 2
Hanging System 3 Hanging System 4
