CCl4MUNICATIONS SECTION 6.4
6,4,3 RECEIVING PARAMETER SCREEN
6,4,4
6,4,5
6,4.6
VER,V09F
Receiving Parameters
Rate-1200
Prtcl-none Pty-none
RTS-off DSR-n DCD-n T/0-no Serig-off
press ENTER if acceptable
To re-select the previous entries, press 'ENTER',
BAUD RATE (Rate)
The available baud rates are:-
1200
75 1800
110 2400
150 4800
300 EXT
600
The EXT feature is to provide for external clocking when using
synchronous protocols,
SELECT PROTOCOL (Prtcl)
The protocols available on HUNTER are:-
NONE
XON/XOFF
ACK/NAK
ETX/ACK
Systime
IBM 2780 (optional)
SELECT PARITY (pty)
On transmission parity is implemented as follows:-
a) None
b) Odd
c) Even
bit 8 is reset, i.e. logical
o.
bit 8 is set or reset to cause an odd number
of logical 1 's in the data bits.
bit 8 is set or reset to cause an even number
of logical
1 's in the data bits,
PAGE 6 - 7
