HUNTER OPERATION
SECTION 2.7
COMMUNICATION
2,7 HUNTER has an industry-standard RS-232/V24 serial communications
port, and will talk directly to most computer peripherals,
modems and other devices.
Fig 2.5 MALE (HUNTER)
3 IQ 12 13
oooaoooooQooo
QQOOOOQQOOOO
14 15 16 17 18 19 20 21 22 23 24 25
The port communicates via a standard male 25-way 'D' type
connector. The pin connections and other data are detailed in
Part 6, COMMUNICATIONS,
NOTE: Never, never try to force a mating connector home. Check
that the connector is the right way up (like this):
Fig 2.6 FEMALE (CABLE)
13 12 II 10 9 8 7 6 5 4 3 2 l
• • • • • • • • • • • • •
•
• • • • • • • • • • •
25 24 23 22 21 20 19 18 17 16 15 14
VER.V09F. PAGE 2 :.: 'fr
