14 – English
SERVICE DATA 336/339XP
Character key
The numbers by bolted components represent
the tightening torque in Nm.
▲ = Lubricate using two-stroke oil.
■ = Lubricate using engine oil.
● = Lubricate using grease.
❑ = Glued using 2 component adhesive.
❍ = Sealed using silicone.
2-3
15
8-10
8-10
20-26
8-10
10-15
*
