5.6 Overhaul
Inspect the component parts of the product. Re-
place damaged parts as described in the relevant
chapter.
A
C
B
Fig 5
5.5 Troubleshooting the BLDC control
unit
Check that the blade terminals and associated
wires are not bent or damaged.
(A) 4.8x0.8mm M phase (Gray wire)
(B) 4.8x0.8mm M phase (Black wire)
(C) 4.8x0.8mm M phase (Red wire)
See gure 5.
Diagnosis and troubleshooting
