Husqvarna AUTOMOWER 310 MARK II User Manual

1.2 Product overview
2
3
5
6
7
8
10
16
15
19
17
20
18
14
12
13
25
27
26
28
29
30
31
9
21
24
23
22
4
11
1
1. Product body
2. Top cover
3. Hatch to keypad, display and cutting height
adjustment
4. Stop button
5. Rear wheels
6. Front wheels
7. Blade disc
8. Skid plate
9. Contact plates
10. LED indicator for operation check of the charging
station and boundary wire
11. Charging station
12. Display
13. Keypad
14. ON/OFF button
15. Rating plate with product identification code
16. Cutting height adjustment
17. Maintenance tool
1
18. Cutting system
19. Chassis box with electronics, battery and motors
20. Handle
21. Loop wire for boundary wire and guide wire
2
22. Couplers for the loop wire
3
23. Stakes
4
24. Connectors for the loop wire
5
25. Screws to attach the charging station
26. Power supply
6
27. Measurement gauge for installation of the
boundary wire (remove the measurement gauge
from the carton of the product)
28. Operator's Manual and Quick Guide
29. Blade
30. Low-voltage cable
1
Found below the top cover.
2
Is a part of the installation kit.
3
Is a part of the Installation kit.
4
Is a part of the installation kit.
5
Is a part of the installation kit.
6
The appearance can be different for different markets.
4 - Introduction 1462 - 007 - 14.03.2022

Husqvarna AUTOMOWER 310 MARK II Specifications

General

Cutting width	22 cm
Cutting height, min-max	20-50 mm
Battery type	Li-ion
Typical charging time	60 min
Typical mow time on one charge	70 min
Sound level perceived	59 dB(A)
Maximum slope performance inside installation	40%
Working area capacity	1000 m²
Cutting system	3 pivoting razor blades
Weight	9.4 kg
Battery voltage	18 V
Battery capacity	2.1 Ah
Maximum area capacity	1000 m²
Noise level	59 dB(A)
Weather resistance	Yes
Security features	PIN code, alarm
Connectivity	Bluetooth
Maximum slope	25% (14°)
