Husqvarna AUTOMOWER 430X User Manual

3023-042
Guide
3023-043
Guide
Guide
English - 88
TROUBLE SHOOTING
3. Switch the connections between the guide wire
and the boundary wire in the charging station.
a) Switch connection AL and G1.
If the indicator lamp is lit with a solid green light,
then the break is somewhere on the boundary
wire between AL and the point where the guide
wire is connected to the boundary wire (thick black
line in the illustration).
b) Put AL and G1 back in their original positions.
Then switch AR and G1.
If the indicator lamp is lit with a solid green light,
then the break is somewhere on the boundary
wire between AR and the point where the guide
wire is connected to the boundary wire (thick black
line in the illustration).
1157866-26,420,430X,450X,EN_160314.indd 88 2016-03-14 17:00:07

Husqvarna AUTOMOWER 430X Specifications

General

Product Name	Husqvarna AUTOMOWER 430X
Category	Lawn Mower
Cutting Width	24 cm
Cutting Height Min	20 mm
Cutting Height Max	60 mm
Battery Type	Li-ion
Typical Charging Time	50 min
Maximum Incline Within the Working Area	45 %
Cutting System	3 pivoting razor blades
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	No
Battery Voltage	18 V
Weight	13.2 kg
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
