Husqvarna AUTOMOWER 430X User Manual

3023-029
3023-030
3023-044
English - 89
TROUBLE SHOOTING
4. a) Assume that the indicator lamp is lit with a solid
green light in test a) above. Reset all connections
to their original positions. Then disconnect AR.
Connect a new loop wire to AR. Connect the other
end of this new loop wire somewhere at the center
of the installation.
If the indicator lamp is green, then the break is
somewhere in the wire between the disconnected
end to the point where the new wire is connected
(thick black line in the illustration below).
In that case, move the connection for the new wire
closer to the disconnected end (roughly at the
middle of the suspected wire section) and check
again if the indicator lamp is green.
Continue until only a very short section of the wire
remains which is the difference between a ashing
blue light and a solid green light.
b) If the indicator lamp is solid green in test 3b)
above, a similar test is carried out but with the
new loop wire connected to AL instead.
1157866-26,420,430X,450X,EN_160314.indd 89 2016-03-14 17:00:09

Husqvarna AUTOMOWER 430X Specifications

General

Product Name	Husqvarna AUTOMOWER 430X
Category	Lawn Mower
Cutting Width	24 cm
Cutting Height Min	20 mm
Cutting Height Max	60 mm
Battery Type	Li-ion
Typical Charging Time	50 min
Maximum Incline Within the Working Area	45 %
Cutting System	3 pivoting razor blades
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	No
Battery Voltage	18 V
Weight	13.2 kg
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
