DESIGN AND FUNCTION
Steering
All mowers in the Rider series have articulated
steering. The steering force from the steering
wheel is transmitted to the rear carriage via a
chain and cables. This makes steering the rider
both easy and precise.
A Rider easily cuts around all obstacles on the
lawn.
A mechanical linkage gives the front wheels a
higher speed when cornering.
The turning circle is very small thanks to the
articulated steering; the uncut circle with full lock is
only 20–30 cm / 8–12" depending on model.
6011-008
Outline diagram of the articulated steering function
6019-007
The Rider machines have steering columns with bearings (1)
