REPAIR INSTRUCTIONS
Removing the Briggs & Stratton engine
1. Remove the engine cover and
transmission cover.
2. Loosen the battery’s retaining strap.
Remove the protective cover and loosen
the cable connections. Then lift out the
battery.
3. Remove the cable connecting the starter
relay to the starter.
4. Pull apart the connector for the engine’s
electrical cables.
5. Remove the clip holding the throttle and
choke cables. Release the cable from its
mounting.
8009-427
IMPORTANT INFORMATION
Hold the bolts so that the poles are not put
under strain.
8009-426
8009-421
8009-402
